Candle Fully Automatic Screen Printing Machine 3200x1120x1520mm IR Drying

Ask Lasest Price
Brand Name :	HONGYU
Model Number :	HY-BG1-80
Certification :	CE
Price :	negotiation
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	30 set/mounth
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

Candle Fully Automatic Screen Printing Machine 3200x1120x1520mm IR Drying

Automatic candle screen printing machine printer,candle printing machine

HY-BG1-80C

This screen printer was designed for small diameter objects such as
candle, pearl pen, pencil, mark pen, board pen, signature pen,
eyebrow pen, labium cream, Injector, chopsticks and high speed
screen printing.

Specification

1. Auto loading with loading tower.
2. Auto dust cleaning: dust cleaned by compressed air. Can be
installed with electric precipitator with extra cost.
3. Two printing lines in one: the machine is combined with 2 printing lines, printing at the same time. The speed can be much
faster and the cost is much lower. The 2 lines printing are
controlled by 1 operator only. And the 2 printing lines can print
different products or different images at the same time.
4.Single color or multi color optional: the single color machine
can be upgraded to multi color printing by adding the registration
system.
5. PLC control, touch screen display.
6. UV curing and IR drying: machine can be installed with UV curing
or IR drying, or with both drying so that the operator can choose
any of them. The machine can be stopped anytime to add ink or clean
the mesh, and the printed products will not be burned in the oven.
7. Cooling system: Products are cooled down before unloading.
8. Auto unloading with unloading slot. Unloading container
attached.
9. Machine is all electric driven except dust cleaning, no
compressed air requirement.
10.Machine built with safety cover to be CE demand.
Parameters:
Objects diameter:φ6~φ20 mmObjects length:55~160 mm
Printing stroke: 20~80 mmMax printing speed:8000 pcs/h
Motor wattage: 4.5kwFeeding Motor: 25W
Mainly Motor: 375WIR Motor: 60W
Cool Motor: 5W.Net weight: 450kg
Max Frame dimension: 150×250mmIR wattage: 1KW(up)+1KW(Down) IR Length: 800mm
